Abrasive Machine

Abrasive Sanding Belt Converting Machine With Continous Skiving Part Glue Coating

Dimension: 4600*850*1700mm
Power: 4.5KW
Voltage: 380V
After Warranty Service: Video technical support, Online support
Description: Abrasive Sanding Belt Converting Machine With Continous Skiving Part Glue Coating
INQUIRY EMAIL

Abrasive Sanding Belt Converting Machine With Skiving Unit & Glue Coating Unit

Skiving machine ABR-ASMG-4 is designed for abrasive cloth/ paper
belt joint preparation which combined joint edge skiving & glue coating.
Continuous feeding system with conveyor belt.
Suitable for tape joint, or overlap joint.
Scuffing units can be customized.
New model of skiving unit, which is easily adjusted.

Technical Info

Standard skiving unit:

1 parallel sanding belt scuffing unit

1 40 degree sanding belt scuffing unit

1 clean & strip disc/ wire brush scuffing unit

1 opposite diamond cup scuffing unit

All scuffing unit are 6-direction adjustable

With air cleaning part

With roller glue coating unit, or spray glue coating (Customer can choose one model)

With a 1.54m baking oven for glue drying

Heating oven temperature: 60~100°C

Continous feeding with conveyor belt

Feeding speed: 10m/min

Fold-able roller table to hold material

Basic Parameter

Power: 4.5KW
Electric supply: 380V, 50HZ
Pneumatic supply: 0.7Mpa

Dimension: 4600*850*1700mm
